At a busy junction in Eindhoven, the Netherlands, cyclists experience round a round bridge suspended above motor site visitors. Often called the Hovenring, the construction resembles a flying saucer held aloft by a tall, cigar-shaped metal pylon. Its round deck has a diameter of 72 metres and is suspended from the central pylon by 24 metal cables. Vehicles and different motor automobiles cross via the junction beneath, whereas cyclists and pedestrians cross above. Designed by Dutch engineering agency ipv Delft, the bridge grew to become a neighborhood landmark for its distinctive type and lighting. Its first interval of use was reduce brief in January 2012, when cable vibrations led to the cycle roundabout being closed. Following repairs and changes, it was formally opened to the general public on 29 June 2012. The designer lists the development value at €6.3 million. Its uncommon look rests on an engineered system of cables, a round counterweight and a tall central pylon.
Hovenring Eindhoven : why town constructed a round cycle bridge above a busy junction
The Hovenring was developed to handle congestion at a junction connecting Eindhoven with Veldhoven and Meerhoven. In an interview revealed by ipv Delft, senior designer and challenge chief Adriaan Kok defined that the prevailing ground-level roundabout carried various kinds of site visitors and was poorly designed for cyclists. The event of a close-by housing property added to the necessity to redesign the intersection to accommodate rising site visitors. Eindhoven needed a substitute for bicycle owner underpasses and a traditional roundabout at highway stage. The town requested ipv Delft to discover doable designs, and the staff developed an elevated round roundabout with 4 connecting bridges. The association permits cyclists and pedestrians to cross above the highway whereas motor automobiles proceed beneath. Kok additionally recognized the junction’s connections in direction of Eindhoven Airport and the A2 motorway as a part of its wider transport context.The design mirrored Eindhoven’s affiliation with lighting and expertise. Often called the Metropolis of Mild due to its historic hyperlinks with Philips, Eindhoven needed an modern construction that used lighting creatively and complemented the close by Evoluon, a futuristic, saucer-shaped constructing. The round bridge supplied a option to mix town’s visible ambitions with a sensible transport answer. Area was a serious constraint. To create snug gradients for the strategy ramps with out considerably increasing the junction’s footprint, the highway stage beneath the bridge was lowered by roughly 1.5 metres. The ramp gradients vary from 2% to simply over 3%, based on ipv Delft. Kok additionally described how the designers addressed native issues concerning the slopes: stakeholders had been invited to cycle over different ramps round Eindhoven whose gradients had been measured prematurely, with out being advised the figures beforehand. The train allowed contributors to evaluate the slopes for themselves.
How 24 metal cables and a concrete counterweight assist the Hovenring
The bridge’s structural design centres on a round deck, a single pylon and 24 metal cables. Somewhat than attaching the cables to the outer fringe of the deck, the designers linked them to its internal facet. In response to ipv Delft’s challenge description, this association helps stop twisting, or torsion, within the deck. In his interview with ipv Delft, Kok defined that the internal round counterweight is partly crammed with concrete and helps stability the deck across the cable attachment factors. The cable placement and counterweight work collectively to assist the round construction. M-shaped helps close to the strategy spans present further stability.The round deck has a diameter of 72 metres, based on ipv Delft. The designer’s specs listing a width of 5 metres. The central pylon rises 70 metres above the bottom. In response to metal fabricator Kersten Group, the pylon is comprised of 23 conical metal segments, with plate thicknesses starting from 20 to 50 millimetres. Kersten additionally describes slotted holes reduce into the within of the pylon the place the cables come collectively. The designers needed a skinny round deck and a powerfully formed pylon. In its challenge description, ipv Delft explains that an ordinary cable-attachment association would have created a cumbersome focus of metal close to the highest of the pylon, so the staff developed a tailored answer. Positioning the pylon in the midst of a busy highway junction additionally required approval from Eindhoven’s site visitors planner.
Hovenring lighting and cable vibrations: the challenges behind the landmark
Lighting is central to the Hovenring’s look after darkish. The house between the round deck and the internal counterweight incorporates aluminium lamellas, translucent sheeting and tubular lights, creating a visual ring of sunshine. LED lighting built-in into the railing illuminates the bridge deck, serving to customers recognise each other’s faces. Extra lights connected to the cable framework and counterweight illuminate the junction beneath, based on ipv Delft. Cable vibrations interrupted the Hovenring’s early use. In January 2012, Dutch regional broadcaster Omroep Brabant reported that the junction had been closed after wind-driven vibrations raised issues concerning the cables’ situation. Engineers investigated the issue earlier than the cycle roundabout might open formally.A 2013 research by T. Argentini, L. Rosa and A. Zasso, titled Experimental Analysis of Hovenring Bridge Keep-cable Vibration, was revealed in WIT Transactions on Modelling and Simulation, quantity 55. The researchers recognized vortex shedding as the reason for the vibrations. This phenomenon happens when wind flowing round a cable produces alternating vortices that may make it vibrate. The paper additionally examined the effectiveness of a Stockbridge-type damper and assessed the fatigue lifetime of the bridge’s keep cables.In an April 2012 report, Omroep Brabant mentioned injury to the cable anchorages had turn into identified in February and that every one the anchor rods had since been changed. Remaining work included portray and lighting, with rain delaying the ultimate coat of paint. The bridge’s reopening preparations additionally concerned measures to regulate cable vibrations. In an interview revealed by ipv Delft, Kok mentioned the staff had put aside a price range for vibration-control measures and finally spent lower than the quantity allotted. The answer included two sorts of dampers designed to handle completely different vibration frequencies.The repairs didn’t proceed solely easily. Omroep Brabant’s protection of the opening reported {that a} mounting error had left dampers improperly fitted, prompting one other closure shortly earlier than the official ceremony. The Hovenring was formally opened on 29 June 2012. The episode illustrates the engineering challenges behind a construction whose placing look relies on a fastidiously balanced system of cables, a central pylon and a round deck.
